Description
TBBCI1-800K420 SNAP-ON BULK CURRENT INJECTION PROBE
The TBBCI1-800K420 is a snap-on Bulk Current Injection probe, expanding the Tekbox product range of affordable EMC pre-compliance test equipment.
The BCI probe has been designed primarily for conducted immunity testing of automotive products in the frequency range 1 MHz to 400 MHz, according to standard ISO11452-4. The insertion loss is 5 dB for most of its bandwidth. In the frequency range 250 kHz to 230 MHz it is compliant with the insertion loss specification of ISO11452-4. The probe is individually characterized and usable in the frequency range 10 kHz – 450 MHz. The probe can be used to inject severity levels I (60mA), II (100mA, III (150mA), IV (200mA) and customer specific severity level V up to 350 mA.
The probe can also be used for RF current monitoring applications.
The aperture of the RF current monitoring probe is 27 mm. The typical insertion loss is 5 dB and the typical transfer impedance is 26 dB Ohm.
